EHBJ-50 Auto Ppie Longitudinal Turntable Welding Positioner With max Ф1500mm Turning Distance
EHBJ-50 Auto Ppie Longitudinal Turntable Welding Positioner With max Ф1500mm Turning Distance
Quickly Details:
Type:Elevating Welding Positioner
Brand:Weld-max
Condition:100% brand new
Model number:EHBJ
Capacity:1000kg-200,000 kg
Consist: (1) Main frame (1) Control box with hand panel
Voltage:110V-600V
Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black
Place of origin:Wuxi , China(Mainland)
Application:
1Pressure vessels.
2Pipe manufacturing industries
3Wind power fabrication
4Chemical & fuel storage tank fabrication
5Any heavy cylindrical job
Product Description:
The positioner can be supplied for interfacing with robot or welding manipulators,to realize the welding automation.The shape and weight of work-pieces,process and working method are provided,our company shall supply a prompt scheme your reference.It can divide into side tilting type , head to tail rotary type, head& tailstock lifting rotary type, head& tailstock tilting type, double rotary type positioner. The positioner can work with welding column& boom to realize the automatic special purpose welding center. As robot peripherals, it can also work with robot to realize automatic welding .
Product Parameter:
|
Model |
Rated load Cap (tons) |
Power (kw) |
Max Gravity height (mm) |
Max |
Table |
Max Rotation Ф@ 90 degree |
Tilt Angle (degree) |
|||
|
Rotation |
Tilt |
Speed(rpm) |
Diameter (mm) |
|||||||
|
Rotation |
Tilt (constant) |
|||||||||
|
EHBJ-10 |
1 |
1.1 |
1.5 |
250 |
200 |
0.05~05 |
0.67 |
1200 |
2000 |
0~120 |
|
EHBJ-20 |
2 |
1.1 |
1.5 |
300 |
200 |
0.05~05 |
0.23 |
1400 |
2100 |
0~120 |
|
EHBJ-30 |
3 |
1.5 |
2.2 |
300 |
200 |
0.05~05 |
0.23 |
1400 |
2100 |
0~120 |
|
EHBJ-50 |
5 |
2.2 |
3 |
300 |
200 |
0.05~05 |
0.14 |
1500 |
2500 |
0~120 |
|
EHBJ-80 |
8 |
2.2 |
4 |
400 |
200 |
0.02~0.2 |
0.14 |
2000 |
3200 |
0~120 |
|
EHBJ-100 |
10 |
3 |
5.5 |
400 |
200 |
0.02~0.2 |
0.14 |
2000 |
3200 |
0~120 |
|
EHBJ-150 |
15 |
3 |
5.5 |
450 |
200 |
0.015~0.15 |
0.1 |
2200 |
3200 |
0~120 |
|
EHBJ-200 |
20 |
4 |
7.5 |
450 |
200 |
0.015~0.15 |
0.1 |
2300 |
3200 |
0~120 |
