Fixed And Motorized Welding Manipulator For Flange Welding
Quickly Details:
Type: Welding Manipulator / Column and Boom
Brand:Weld Max
Condition:100% brand new
Model number:LH S
ize:LH-1010-LH-8080
Consist: (1) Column, (1) Boom , (1)Travel cart, (1) Control box with hand panel
Voltage:110V-600V
Painting Color:Yellow
Place of origin:Wuxi , China(Mainland)
Application:
1. Pressure vessels welding
2. Pipe manufacturing industries
3. Wind power fabrication
4. Chemical & fuel storage tank fabrication
5. Any heavy cylindrical welding job
Product Description:
Manipulator machine is composed of a column (including lifting mechanism, a sliding seat part, column slewing part, anti falling safety device and a balance weight), a boom (including rack and a transverse drive part), welding torch adjustment mechanism, column slewing mechanism components.
The automatic welding machine can weld metal containers and welded structural parts in various ways. It is widely used in wind power equipment, pressure vessel, petrochemical, pipeline, steel structure, boiler, shipbuilding, surfacing repair and many other industries. Electric trailers, telescopic booms, manned devices and maintenance ladders can be installed according to user’s requirements. Various tracking and monitoring devices, arc swing, flux recovery and conveying devices can also be matched.
Product Parameter:
|
Model |
Boom |
Column |
Traveling cart |
Power KW |
|||||
|
Vertical stroke(A)m |
Horizontal stroker(B)m |
Elevation speed m/min |
Traverse speed m/min |
Max load at extremity kg |
Total height(C)m |
Dimensions |
Rail c to c(F)mm |
||
|
LH1515 |
1.5 |
1.5 |
0.3 |
0.12~1.2 |
100 |
2.9 |
1.25×1.2×0.2 |
1052 |
0.91 |
|
LH2020 |
2.0 |
2.0 |
0.3 |
100 |
3.4 |
1.25×1.2×0.2 |
1052 |
0.91 |
|
|
LH3030 |
3.0 |
3.0 |
1.0 |
200 |
5.5 |
2.4×1.9×0.4 |
1600 |
2.75 |
|
|
LH3040 |
3.0 |
4.0 |
1.0 |
200 |
5.5 |
2.4×1.9×0.4 |
1600 |
2.75 |
|
|
LH4040 |
4.0 |
4.0 |
1.0 |
200 |
6.5 |
2.4×1.9×0.4 |
1600 |
2.75 |
|
|
LH4050 |
4.0 |
5.0 |
1.0 |
200 |
6.5 |
2.4×1.9×0.4 |
1600 |
2.75 |
|
|
LH5050 |
5.0 |
5.0 |
0.9 |
300 |
7.8 |
2.6×2.1×0.5 |
1798 |
3.5 |
|
|
LH5060 |
5.0 |
6.0 |
0.9 |
300 |
7.8 |
2.6×2.1×0.5 |
1798 |
3..5 |
|
|
LH6060 |
6.0 |
6.0 |
0.9 |
300 |
9.7 |
2.6×2.1×0.5 |
1798 |
3.5 |
|
