Wholesale Dealers of 40ton Hydraulic Welding Rotator - 50T Conventional Welding Rolls With 2*2.2KW Motor – Sanlian
Wholesale Dealers of 40ton Hydraulic Welding Rotator - 50T Conventional Welding Rolls With 2*2.2KW Motor – Sanlian Detail:
Quickly Details:
Type:Conventional Welding Rotator
Brand:Weld-Max
Condition:100% brand new
Model number:HGK
Capacity:5Ton – 1000Ton
Consist: (1) Drive unit , (1) Idler unit , (1) Control box with hand panel
Voltage:110V-600V
Painting Color:Yellow & Blue /Yellow & Grey / Yellow & Black / Red&Black
Place of origin:Wuxi , China(Mainland)
Product Description:
This equipment consistd of one set drive rotator,one set idler rotator and control system,cause the vessel diameter more big so we used double driver type,means two motor with driver gear reducer drive to toller to rotation,so the Large driving capacity with lower failure rate.Roller bed are fixed type and all of roller with best quantity of PU without steel wheel support,especial big tons rotator used the PU wihch both drive friction and support strength can be guaranteed,we guarantee used two years and will not broken.
Application:
Welding rotator is mainly used for cylindrical tank’s welding, polishing, rubber lining, assembling ,etc, and it’s also can match up with other tools for welding or assembling for cone and section equality solid of revolution. It’s widely used for many industries such as wind powder, pressure vessel, petrochemical, pipeline, steel structure, boiler, shipbuilding, surfacing welding rebuilding, etc. We also can offer customized special welding rotators according to client’s requirements.
Product Parameter:
|
Type |
Max loading (kg) |
Vessel diameter(mm) |
Dia. and width of the wheel(mm) |
Roller linear velocity(m/h)
6-60
|
Power of motor(kw) |
|
|
Rubber rollers |
Metal rollers |
|||||
|
HGK-5 |
5,000 |
Φ250-2300 |
Φ250×100 |
2×Φ240×20 |
2X0.37 |
|
|
HGK-10 |
10,000 |
Φ320-2800 |
Φ300×120 |
2×Φ290×25 |
2X0.55 |
|
|
HGK-20 |
20,000 |
Φ500-3500 |
Φ350×120 |
2×Φ340×30 |
2X0.75 |
|
|
HGK-40 |
40,000 |
Φ600-4200 |
Φ400×120 |
2×Φ390×40 |
2X1.5 |
|
|
HGK-60 |
60,000 |
Φ750-4800 |
Φ450×120 |
2×Φ440×50 |
2X2.2 |
|
|
HGK-80 |
80,000 |
Φ850-5000 |
Φ500×120 |
2×Φ490×60 |
2X3 |
|
|
HGK-100 |
100,000 |
Φ1000-5500 |
Φ500×120 |
2×Φ490×80 |
2X3 |
|
|
HGK-150 |
150,000 |
Φ1000-6000 |
/ |
Φ620×220 |
2X4 |
|
|
HGK-250 |
250,000 |
Φ1800-7500 |
/ |
Φ660×260 |
2X5.5 |
|
|
HGK-500 |
500,000 |
Φ1800-8000 |
/ |
Φ750×400 |
2X7.5 |
|
Product detail pictures:
